- 產品型號：57297494
- 頻率：25.0MHz
- 尺寸：3225mm
- 產品介紹：X1E000021035200,EPSON穿戴設備晶振,25MHz晶振,3.2×2.5mm緊湊型3225封裝,超薄0.6mm厚度適配穿戴輕薄化趨勢,常溫精度±10ppm,適配穿戴設備小容量鋰電池供電.
-
X1E000021035200,EPSON穿戴設備晶振,25MHz晶振
.png)
X1E000021035200,EPSON穿戴設備晶振,25MHz晶振
X1E000021035200為愛普生TSX-3225系列25MHz無源貼片晶振,專為智能穿戴設備晶振打造,3.2×2.5×0.6mm超薄3225四腳封裝,適配手表,手環,藍牙耳機等小型低功耗終端.常溫頻差±10ppm,全溫區間-40℃~+85℃穩定度±18ppm,20pF標準負載電容,最大ESR僅40Ω,100μW低激勵功率,大幅降低穿戴設備耗電,延長續航.采用AT切原廠石英工藝,年老化率≤1ppm,信號抖動小,保障藍牙,傳感器時鐘同步精準.無鉛環保,編帶SMT適配自動化貼片,抗震動耐溫差,長期運行無頻漂,是穿戴設備主控,無線模塊標配時鐘元件.
.png)
X1E000021035200,EPSON穿戴設備晶振,25MHz晶振
| 原廠型號 Originalmodel： | X1E000021035200 | 品牌brand： | EPSON |
| 品牌brand： | EPSON | 高度PackageHeight： | 0.7mm |
| 型號名稱 Modelname： | 愛普生TSX-3225晶振 | 溫度OperatingTemperature | -40+85℃ |
| Type系列： | MHz Crystal | 腳位Termination： | 4-pad |
| 頻率 frequency： | 25M | 封裝類型PackageType： | 4-smd |
| frequencytolerance頻率容差 | ±10ppm | 最小包裝數MPQ： | 3000 |
| Loadcapacitance 負載電容 | 20PF | Packaging 包裝 | TapeandReel |
| Size/Dimension尺寸 | 3225 | 安裝方式 Installation： | Surfacemount |
.png)
X1E000021035200,EPSON穿戴設備晶振,25MHz晶振
.png)
X1E000021035200,EPSON穿戴設備晶振,25MHz晶振
| SG-8018CG 19.843750M-TJHPA0 | EPSON | SG-8018 | XO | 19.84375 MHz |
| SG-8018CG 148.4258M-TJHPA0 | EPSON | SG-8018 | XO | 148.4258 MHz |
| SG-8018CG 19.6608M-TJHPA0 | EPSON | SG-8018 | XO | 19.6608 MHz |
| SG-8018CG 12.9876M-TJHSA0 | EPSON | SG-8018 | XO | 12.9876 MHz |
| SG-8018CG 16.3960M-TJHPA0 | EPSON | SG-8018 | XO | 16.396 MHz |
| SG-8018CG 4.8250M-TJHPA0 | EPSON | SG-8018 | XO | 4.825 MHz |
| SG-8018CG 26.9900M-TJHPA0 | EPSON | SG-8018 | XO | 26.99 MHz |
| SG-8018CG 19.692307M-TJHPA0 | EPSON | SG-8018 | XO | 19.692307 MHz |
| SG-8018CG 98.7650M-TJHPA0 | EPSON | SG-8018 | XO | 98.765 MHz |
| SG-8018CG 98.3040M-TJHPA0 | EPSON | SG-8018 | XO | 98.304 MHz |
| SG-8018CG 32.5710M-TJHPA0 | EPSON | SG-8018 | XO | 32.571 MHz |
| SG-8018CG 33.2300M-TJHPA0 | EPSON | SG-8018 | XO | 33.23 MHz |
| SG-8018CG 38.9100M-TJHSA0 | EPSON | SG-8018 | XO | 38.91 MHz |
| SG-8018CG 32.507937M-TJHPA0 | EPSON | SG-8018 | XO | 32.507937 MHz |
| SG-8018CG 4.9150M-TJHPA0 | EPSON | SG-8018 | XO | 4.915 MHz |
| SG-8018CG 135.0000M-TJHPA0 | EPSON | SG-8018 | XO | 135 MHz |
| SG-8018CG 73.3337M-TJHPA0 | EPSON | SG-8018 | XO | 73.3337 MHz |
| SG-8018CG 12.3540M-TJHPA0 | EPSON | SG-8018 | XO | 12.354 MHz |
| SG-8018CG 102.4000M-TJHSA0 | EPSON | SG-8018 | XO | 102.4 MHz |
| SG-8018CG 4.5160M-TJHSA0 | EPSON | SG-8018 | XO | 4.516 MHz |
| SG-8018CG 148.0000M-TJHPA0 | EPSON | SG-8018 | XO | 148 MHz |
| SG-8018CG 16.6000M-TJHSA0 | EPSON | SG-8018 | XO | 16.6 MHz |
| SG-8018CG 56.0580M-TJHSA0 | EPSON | SG-8018 | XO | 56.058 MHz |
| SG-8018CG 122.2000M-TJHSA0 | EPSON | SG-8018 | XO | 122.2 MHz |
| SG-8018CG 99.1440M-TJHPA0 | EPSON | SG-8018 | XO | 99.144 MHz |
| SG-8018CG 4.9600M-TJHSA0 | EPSON | SG-8018 | XO | 4.96 MHz |
| SG-8018CG 134.7840M-TJHPA0 | EPSON | SG-8018 | XO | 134.784 MHz |
| SG-8018CG 16.5800M-TJHPA0 | EPSON | SG-8018 | XO | 16.58 MHz |
| SG-8018CG 99.751230M-TJHSA0 | EPSON | SG-8018 | XO | 99.75123 MHz |
| SG-8018CG 22.597240M-TJHSA0 | EPSON | SG-8018 | XO | 22.59724 MHz |
| SG-8018CG 101.2656M-TJHPA0 | EPSON | SG-8018 | XO | 101.2656 MHz |
| SG-8018CG 32.7680M-TJHSA0 | EPSON | SG-8018 | XO | 32.768 MHz |
| SG-8018CG 4.433619M-TJHPA0 | EPSON | SG-8018 | XO | 4.433619 MHz |
| SG-8018CG 4.7500M-TJHSA0 | EPSON | SG-8018 | XO | 4.75 MHz |
| EG-2121CA 200.0000M-PHPAL3 | EPSON | EG-2121CA | SO SAW | 200 MHz |
| EG-2121CA 200.0000M-PHPAB | EPSON | EG-2121CA | SO SAW | 200 MHz |
| EG-2121CA 156.2500M-LHPAB | EPSON | EG-2121CA | SO SAW | 156.25 MHz |
| EG-2102CB 156.2500M-LGPAL3 | EPSON | EG-2102CB | SO SAW | 156.25 MHz |
| SG3225EEN 156.250000M-DJGA3 | EPSON | SG3225EEN | XO | 156.25 MHz |
| SG3225VEN 156.250000M-CJGA3 | EPSON | SG3225VEN | XO | 156.25 MHz |
| SG7050EEN 156.2500M-CJGA3 | EPSON | SG7050EEN | XO | 156.25 MHz |
| SG7050EEN 156.2500M-CDGA3 | EPSON | SG7050EEN | XO | 156.25 MHz |
| EG-2121CA 250.0000M-LGPAB | EPSON | EG-2121CA | SO SAW | 250 MHz |
| TG2520SMN 27.6000M-ECGNNM3 | EPSON | TG2520SMN | TCXO | 27.6 MHz |
| VG-4231CE 12.2880M-CSCM3 | EPSON | VG-4231CE | VCXO | 12.288 MHz |
| XG-2102CA 250.0000M-PGPAL3 | EPSON | XG-2102CA | SO SAW | 250 MHz |
| SG3225HBN 212.500000M-CJGA3 | EPSON | SG3225HBN | XO | 212.5 MHz |
| EG-2121CA 125.0000M-LHPAL3 | EPSON | EG-2121CA | SO SAW | 125 MHz |
| SG3225VEN 125.000000M-CJGA3 | EPSON | SG3225VEN | XO | 125 MHz |
| SG3225EEN 100.000000M-CJGA3 | EPSON | SG3225EEN | XO | 100 MHz |
| SG3225EEN 25.000000M-CDGA3 | EPSON | SG3225EEN | XO | 25 MHz |
| SG-210STF 27.0000ML0 | EPSON | SG-210STF | XO | 27 MHz |
| SG3225CAN 50.0000M-TJGA6 | EPSON | SG3225CAN | XO | 50 MHz |
| SG3225CAN 48.0000M-TJGA6 | EPSON | SG3225CAN | XO | 48 MHz |
| SG7050CCN 16.000000M-HJGA0 | EPSON | SG7050CCN | XO | 16 MHz |
| SG-210STF 27.0000ML3 | EPSON | SG-210STF | XO | 27 MHz |
| SG-210STF 24.5760MS3 | EPSON | SG-210STF | XO | 24.576 MHz |
| SG-210STF 12.2880MS3 | EPSON | SG-210STF | XO | 12.288 MHz |
| TG2016SMN 19.2000M-MCGNNM0 | EPSON | TG2016SMN | TCXO | 19.2 MHz |
| TG2016SMN 38.4000M-ECGNNM0 | EPSON | TG2016SMN | TCXO | 38.4 MHz |
